ECMA-E21310RS Detla AC Servo Motor 220V 1KW 4.77NM 2000rpm 130mm with Keyway oil seal New CNC

item ID#: ECMA-E21310RS
Item condition: New and Original
No reviews Write a review
Weight: 8 Kg(s)
10 available/ 0 sold
Start from: 1 Unit(s)
Manufactured by: Delta
Wholesale Price: 343.00
Quantity: Unit(s)
  • DHL Recommended Shipping
  • Stock Lead Time

Estimate Shipping Costs

  • Description
  • Download
  • Reviews
  • Write a Review

ECMA-E21310RS Detla AC Servo Motor 220V 1KW 4.77NM 2000rpm 130mm with Keyway oil seal New


fasttobuy logo(229).jpg



Contact information:

Phone: +0086 13724354369  or +0086 755 82546545
email: service@fasttobuy.com   skype: fasttobuy02
our working time: EST 9:00AM ~ 6:00 PM



AC Servo Motor ECMA-E21310RS available, if need other choices, contact us directly. we can also supply ECMA-E21310SS.


Motor Specifications:


Model

ECMA-E21310RS

Product Name

Electronic Commutation Motor

Corresponding Servo Motor

ASD-B2-1021-B

Servo Type

AC Servo

Rated Voltage

220V

Encoder Type

Incremental, 17-bit

Motor Frame Size

130mm

Type of Shaft Diameter and Oil Seal

Keyway(with fixed screw holes)  w/o Brake with Oil Seal

Shaft Diameter

S=22mm

Rated Power Output

1000W

Rated torque (N-m)*1

4.77

Max. torque (N-m)

14.32

Rated Speed

2000 rpm

Max. speed

3000 rpm

Rated current (A)

5.6

Max. current (A)

16.8

Power rating (kW/s)(without brake)

27.1

Rotor moment of inertia(× 10 -4 kg.m2 )

8.41

Mechanical time constant(ms)

1.51

Torque constant-KT (N-m/A)

0.85

Voltage constant-KE (mV/(r/min))

31.9

Armature resistance (Ohm)

0.47

Armature inductance (mH)

5.99

Electrical time constant (ms)

12.88

Insulation class

Class A (UL), Class B (CE)

Insulation resistance

> 100 M ohm, DC 500 V

Insulation strength

AC 1500V, 60 sec

Weight (kg)  (without brake)

7.0 Kg

Max. radial shaft load (N)

490

Max. thrust shaft load (N)

98

Vibration grade (μm)

15

Operating temperature

0~40  degree centigrade

Storage temperature

-10~80  degree centigrade

Operating humidity

20% to 90% RH (non-condensing)

Storage humidity

20% to 90% RH (non-condensing)

Vibration capacity

2.5G

IP Rating

IP65

Approvals

CE  UL
