2 Phase NEMA34 Stepper Motor Kits Closed Loop Control 8.5NM With 1000line Encoder For CNC Router

item ID#: 2HSS86H+86J18118EC-1000(φ60)
Item condition: New and Original
No reviews Write a review
Weight: 6 Kg(s)
43 available/ 7 sold
Start from: 1 Unit(s)
Manufactured by: JMC
Wholesale Price: US$156.00
Discount Price: 134.00
Quantity: Unit(s)
  • DHL Recommended Shipping
  • Stock Lead Time

Estimate Shipping Costs

  • Description
  • Download
  • Reviews
  • Write a Review

2 Phase NEMA34 Stepper Motor Kits Closed Loop Control 8.5NM With 1000line Encoder For CNC Router

fasttobuy logo(42).jpg

Contact information:

Email: service@fasttobuy.com
skype: fasttobuy02
our working time: EST 9:00AM ~ 6:00 PM

 Packing List


2HSS86H  Closed Loop Stepper Drive


86J18118 EC-1000(φ60 ) Closed-loop stepper motor


encoder cable

Main application fields

Advertising industry, Engraving, packaging, lasers, electron industry, medical industry, Printing industry,

woodworking, machinery industry, Ceramic Industry, stone industry and so on.

Brief introduction

2HS two phase hybrid stepper servo drive system integrated servo control technology into the digital step driver.

It adopts typical tricyclic control method which include current loop,speed loop and position loop.

This product has the advantage of both step and servo system, is a highly cost-effective motion control products.


  1.  Full closed loop control, motor encoder with 1000 line, close to 100% of the torque output
  2.  Segment set range is 2-256, fast response, high speed, light isolation fault alarm output interface ALM
  3.  Current loop bandwidth (-3 db) 2 KHZ (typical), speed loop bandwidth 500 hz (typical), the position loop bandwidth 200 hz (typical)
  4.  RS232 serial port communication available to download or change parameters
  5. Over-current, over-voltage, undervoltage, overheating, speeding, differential protection; Alarm clear input ENA

Benefit for you

(1)Using better manufacturing technology, enabling high quality and refined using experience

(2)Excellent service, a variety of models to meet your needs

(3) One year warranty for the products and lifelong technical support

Shop with confidence, we are always there for you.

Drive specification

Model 2HSS86H
Current 0-7A
Voltage DC(40-110V)  AC(60-80V)
Matched motor 57mm  86mm  110mm
Weight 0.60kg
Dimension 150mm*97.5mm*53mm
Control signal Differential

Motor specification

Model 86J18118EC-1000
Step Angle 1.8°
Holding Torque 8.5NM
Current/Phase 5A
Resis Tance/Phase 0.44
Inductance/Phase 4.4
Detent Torque /Rotor Inetria 1300 /2700



About Fasttobuy:

Fasttobuy Co .,Ltd . was established with the vision of developing motion control product for the industry .Our company has accumulated several years of experience in this field , integrating research and development, manufacture and marketing. We are always striving to understand the needs of customers, and to develop further in this field.

Our main products are stepper motor drives, step motor, AC servo motor systems, DC brushes and brushless motors and drive systems, and  intelligent step motors .we also provide complimentary mechanical products, such as motor couplings, gearboxes, and linear motions.
