Water Cooled Frequency Control 4.5KW 380V Engraving Spindle System ER20 24000rpm With Spindle Motor Controller

item ID#: GDZ100-4.5-380V+E550-4t0055L
  • Item condition: New and Original
  • 10 available/ 0 sold
  • Start from: 1 Unit(s)
  • Weight: 22 Kg(s)
  • Manufactured by: Made in China
  • DHL Recommended Shipping
  • Stock Lead Time
Delivery:
3-7 Days Details
Payment:
Details
Guarantee:
1Year Quality Assurance Details
Returns:
7 days unconditional return, the buyer bear the return freight Details

Estimate Shipping Costs

Quantity: Unit(s)
US$631.00 + Shipping Cost
    • Description
    • Download
    • Product Reviews
    • Write a Review

    the expert of cnc parts(43).jpg

    Water Cooled Frequency Control 4.5KW 380V Engraving Spindle System ER20 24000rpm With Spindle Motor Controller


    Package Content:

    1*4.5KW Spindle Motor: GDZ100-4.5-380V

    1*5.5KW sunfar VFD Variable Frequency Drive: E550-4t0055L

    1*Cast Aluminium Bracket

    1* Cooling Pump& Pipe

    Spindle Motor Specification:

    Providing the default Nut ER20 and Collet 6mm, if not please do contact us for a better solution.

    Spindle Specifications

    Model No.

    GDZ100-4.5-380V

    Product type

    High-Speed Constant Torque Motorized Spindle Motor  for CNC engraving machines

    Diameter&length

    100 * 260mm

    Speed

    24000rpm

    Power

    4.5KW

    Voltage

    380V

    Current

    10A

    Frequency

    400HZ

    Joint of nose

    ER20

    Lub

    grease

    Cool

    Water-cooled

    Bearing type

    2X7005CP4 , 2X7003CP4 DT

    Collet

    ER20

    Collet nut

    6mm default

    Wattantyperiod

    bearings=half a year other parts a year

    Brand

    Chang sheng(Made in China)

    VFD Specification:

    Model

    E550-4t0055L

    Power (KW)

    5.5KW

    Input Voltage(V)

    3-phase AC 380V ±20% 50/60Hz

    Output Voltage(V)

    0~380V

    Output Current(A)

    13A

    Output Frequency (Hz)

    0~1000Hz

    Origin& Warranty&brand

    China & One year&sunfar

    Bracket Specifications

    Type

    Φ100mm Bracket

    Material & Origin

    Cast Aluminium& China

    Cooling Pump&5M Pipe Specifications

    Model

    Cooling Pump

    Power

    75W

    Voltage(V)

    220~240V AC 50Hz

    Hmax

    3.2M

    Qmax

    3000L/H

    Pipe

    5m



    Shipment:

    1. Usually we will ship the items within 3 working days after the payment is reached.
    2. DHL, UPS, Fedex, or EMS is available for shipping.
    3. Delivery time:DHL, UPS, Fedex, EMS express shipping usually take 3-10 working days depends on the country delivered to.
    4. Please check out your ADDRESS carefully when processing order.
    5. Buyers please note: Accessories tariffs must be buyers to pay.The buyer can choose EMS express to avoid tariffs.
    6. Any accidents, delays or other issues are the responsibility of the shipping service.

    We promise to:

        Offer our customers the low Chinese price.
        Streamline the buying and paying process.
        Deliver goods to our customers all over the world with speed and precision.
        Ensure the excellent quality of our products.
        Help you find products and manufacturers in China.

    Return Policy:

        We accept 14 days return policy. If you want to return the item, please contact us in 14 days first and make sure the package is un-opened.

    The buyer has to pay for the go and back delivery cost and the custom fee of each country. Once we received the product and checked, we will

    make refund for the part in 24 hours.
        Any quality problem in normal use during the warranty period, we will repair for free. The buyer should pay the return cost and our company

    will pay the re-shipping cost.
