New Universal AC VFD 1.5KW 1Phase 220V VC V/F Control Digital Inverter Frequency Converter Output 400Hz 7A for Spinning Machine

Shipping list

VFD basic parameters

Other technical parameters

Advantage

• Maximum  frequency: Vector control: 0–400 Hz    V/F control: 0–600 Hz

• Carrier frequency:0.5–16 kHz

• Frequency setting mode:Digital Settings; Analog Settings; serial communication settings; PID settings

• Input frequency resolution: Digital setting: 0.01 Hz;Analog setting: maximum frequency x 0.025%

• Control mode:1.Sensor less flux vector control (SFVC);2.Closed-loop vector control (CLVC);3.Voltage/Frequency (V/F) control

• Startup torque:G type: 0.5 Hz/150% (SFVC); 0 Hz/180% (CLVC);P type: 0.5 Hz/100%

• Speed range:1:100  (SFVC), 1:1000 (CLVC)

• Standard functions:V/F curve; V/F separation;Ramp mode; DC braking; JOG control;simple PLC function; Onboard multiple preset speeds;
  Onboard PID; Auto voltage regulation (AVR)

• Individualized  functions:high-performance current vector control technology;Power dip ride through;Rapid current limit; Virtual I/Os; Timing control;
  Multi-motor switchover;  RS485 Modbus;Motor overheat protection; Multiple encoder types

More choices available(please leave a message)

The VFD can be used in many place,such as: FAN and Water pump,Electrial equipment, Packging equipment,CNC equipment;
