NEW DIY CNC 3 Axis kits 57mm NEMA23 1.8NM 255oz.in stepper motor&128 microstep driver&DB25 cable+FREE OFFER!CNC breakout board CNC

NEW DIY CNC 3 Axis kits 57mm NEMA23 1.8NM 255oz.in stepper motor&128 microstep driver&DB25 cable+FREE OFFER!CNC breakout board

Note: If you need the dual shaft stepper motor, please leave message to us after order , If no message left, we will ship the single shaft .

Package Including:

• 3 x MB450A Sumtor step motor drive 2ph 24~50VDC 1.1~4.2A
• 3 x 57BYG 2ph Hybrid stepper motor 57HS7630A4 L 76mm 4-lead 3A 1.8NM 1.8 degree
• 1 x Switching Power Supply 350W 36V 9.7A for CNC Router Kits 115V/230V S-350-36
• 1 x 5 Axis CNC Breakout Board Interface For Stepper Motor Driver
• 1 x DB25 Parallel Cable & USB Power Cable

stepper motor: 57HS7630A4

• Product specifics:
• Shaft length: 21mm D Single flat
• Shaft: 6.35mm milling flat of 0.5mm
• is customized : yes
• holding torque: 1.8nm
• type: hybrid
• brand name: sumtor
• phase: 2
• current : 3A
• certification: CCC,CE, ISO
• step angle: 1.8degree

Stepper driver:M450A

Wiring Description

Power supply: S-350-36

5 axis CNC Breakout Board:

• High performance, cost-effective.
• Maximum support 5-axis stepper motor driver controllers.
• Compatible with MACH3, Linux CNC (EMC2) etc. parallel-control CNC software.
• USB power supply and peripherals powered phase are separated to protect computer security.
• All the signals are opto-isolated which can protect your computer security.
• 5-input interface to define the Limit, Emergence-Stop, Cutter alignment etc.
• Wide input voltage range: 12-24V, and with anti-reverse function.
• One relay output control interface, accessed by the spindle motor or the air pump, water pump, etc.
• Output 0-10V analog voltage for inverter to control the spindle speed.

Electrical properties (ambient temperature Tj = 25C pm):
