Multi-functional CNC Engraving Machine CNC1310 110VAC-240AC DIY Small Engraving Machine for Plastics/Wood/Acrylic/PVC/PCB

Multi-functional CNC Engraving Machine CNC1310 110VAC-240AC DIY Small Engraving Machine for Plastics/Wood/Acrylic/PVC/PC

---

1.  Highly portable with compact size and light weight, very easy for you to carry everywhere

2.  Very strong & durable, can be used long, with aluminum frame and work-piece

3.  Very easy to use, even for DIY beginners with USB interface, GRBL control systems

4.  It can be used both for inscribing & laser cutting with multifunctional design for mounting laser head.

(Laser shall be bought, different power options are available)

Control software: GRBL Control

Material: Aluminum

Scope of work: 126 *88* 38mm

Workbench size: 15 0*80mm

Frame size: 281 *281* 287.5mm

Spindle: 775 spindle motor (12-36V) 24V: 8000r/min

Stepping motor: 2-phase 4-wire stepping motor. 1.3A 0.25NM

Screw rod: T8 screw rod

Adapter power supply: 110VAC-240VAC

Equipment needs power supply: 24VDC

Support System: Windows XP/Win 7/Win 8/Linux

This equipment can be used to engrave plastics, wood, acrylic, PVC, PCB and other soft materials .

Can also be  used on  soft matel like copper, aluminum and other materials , but only for simple font surface inscribing

Note: Workpiece materials should be in standard shap e. Works best with cylindrical . curved surface, non-isotropic materials can not be engraved.

Equipped with laser head: cardboard, wood, acrylic, PVC, EVA and other materials. Laser burning c olor and depth of burning varies with laser power.

Attention:

1.This machine does not work well on metal, only for simple surface inscribing .  Mainly used to engrave wood.  Please contact us for further information.

2.  Be careful when using laser, pls don’ t look directly at the laser. Protection glasses are suggested when using

3. Do not expose  human skin to the laser for a long time

Frequently Asked Questions:

Q: What ’s the difference  between 500mw laser, 2500mw laser, 5500mw laser

A: All these lasers can not engrave/mark on metal, they are mainly used on engraving wood.

2500mw laser can cut about 1mm normal wood.

5500mw laser can cut about 2mm normal wood, engrave on leather and soft plastic.

CNC1310-No Laser Package : All parts of the machine+4pcs plates+  free 12 pcs pcb cutter+Adapter

Please note:

1. All products are shipped in bulk,Some core components have been assembled, it can be easily assembled according to the installation instructions, you can use the rack

2. If you need laser engraving function, please select according to attributes.

3. ER11 chuck is not included, pls feel free to contact if you need it
