CNC Spindle Motor Controller Kits 2.2kw ER25 220VAC Air Cooled Spindle Motor & Sunfar VFD Inverter For CNC Engraving

item ID#: GDZ93*82-2.2-220V+E550-2S0037L
  • Item condition: New and Original
  • 10 available/ 0 sold
  • Start from: 1 Unit(s)
  • Weight: 14 Kg(s)
  • Manufactured by: Made in China
  • DHL Recommended Shipping
  • Stock Lead Time
Delivery:
3-7 Days Details
Payment:
Details
Guarantee:
1Year Quality Assurance Details
Returns:
14 days unconditional return, the buyer bear the return freight Details

Estimate Shipping Costs

Quantity: Unit(s)
US$545.00 + Shipping Cost
    • Description
    • Download
    • Product Reviews
    • Write a Review

    the expert of cnc parts(51).jpg

    CNC Spindle Motor Controller Kits 2.2kw ER25 220VAC Air Cooled Spindle Motor & Sunfar VFD Inverter For CNC Engraving




    Package Content:

    1*2.2kW Spindle Motor: GDZ93*82-2.2-220V

    1*3.7KW sunfar VFD Variable Frequency Drive: E550-2S0037L

    Spindle Motor Specification:

    Providing the default Collet ER25 6mm, if not please do contact us for a better solution.

    Specifications

    Model

    GDZ93x82-2.2-220V

    Product type

    Square High-Speed Motorized Spindle Motor for Woodworking

    Speed (r/min)

    18000rpm

    Power (KW)

    2.2KW

    Voltage(V)

    220V

    Current(A)

    10A

    Frequency (Hz)

    300HZ

    Collet

    ER25 6mm (default)

    Lubrication

    Grease

    Cooling type

    Air-cooled

    Bearings

    2x7007 P4

    2x7002c P4

    Brand

    Changsheng(Made in China)

    VFD Specification:

    Model

    E550-2S0037L

    Power (KW)

    3.7KW

    Input Voltage(V)

    1-phase AC 220V ±20% 50/60Hz

    Output Voltage(V)

    0~220v

    Output Current(A)

    16.5A

    Output Frequency (Hz)

    0~1000Hz

    Origin& Warranty&brand

    China & One year&sunfar

    Electric spindle practices


    Electric spindle is a high-speed high-precision components rigidity, we must strictly follow the practices used spindle spindle motor, otherwise it will increase equipment failures, shorten equipment life. Please use the rule as follows:


    (1) Before the boot, first ensure that the spindle cooling system to work properly, and then turn the power spindle. If the spindle is water cooled, to check whether the cooling water containing impurities to ensure water is smooth.


    (2) When using electric spindle, spindle from low according to the principle of high speed, gradually increasing speed to warm up, when the spindle load up to speed and smooth operation of the state after the required processing, can better protection spindle, to reduce the wear.


    (3) during use is strictly prohibited beat, hit threaded spindle clamp and rotor end, so as not to reduce the component life, affect the results spindles used.


    (4) During the operation, the tool must be replaced in the correct way. When the knife, the focus should be uniform, the tool should be aligned with the threaded end of the screw rotor, clamping can be. During operation the tool needs to be replaced before the replacement to wait Spindle cooling, avoid tool change at hot temperature state.


    (5) During the operation, if the fixture card spindle rotor end, non-beat way to remove Jigs. Only under the premise of no damage to the rotor shaft threads with pliers and other tools to remove the chuck, and clean the rotor tapered bore and clamp the spindle to avoid Movies shorten life, affecting the quality of workpiece. If the fixture has completely lost precision, it must be replaced immediately.




    The spindle maintenance specification:


     (1) to control the spindle actual time worked. Theoretically prohibit spindle 24 hours of continuous work, operating 12 hours per spindle Spindle let rest at least 2 hours, in order to prevent the formation of shortened due to mechanical fatigue life of the spindle.


     (2) to understand the conditions, the ambient temperature and the spindle temperature control. Spindle operating ambient temperature not higher than 35 centigrade degree, when the ambient temperature is above 35 centigrade degree should use air conditioners or other protective measures to reduce the room temperature, thereby reducing spindle temperature.


     (3) The spindle cooling water must be kept clean and free of impurities, recommendations to clean up after the end of the spindle shaft waterway, scale and water holes to avoid clogging due to rust. Also, always pay attention to circulating water temperature in the tank, so the water temperature is too high, the cooling effect can not be achieved prefetching.


    (4) Always check the power supply connector, to avoid damage to the connector loose or aging brings to the spindle and the drive.


    (5) If the downtime to use again, you must tranches from low speed to high speed spindle run-in steps according to the spindle load running, in order to use in the run-through.


    (6) during the loading and unloading cutter knife, must tool chuck nut clean.






    Use Caution


    (1) must match the drive spindle chosen correctly according to the electric spindle nameplate good debugging power, voltage and frequency.


    (2) Set the frequency converter should be set command channel, and then set the display channel, and finally set the parameters. When setting parameters, be sure that the reference frequency, the frequency of the three highest rated frequency and consistency.


    (3) The spindle is generally clockwise in the wrong direction, the drive can change settings or swap any two rotating wire the inverter output UVW terminal on.


    (4) In general, water-cooled spindle surface temperature and ambient temperature greater than 20 degrees, the heat can be considered a spindle; when air-cooled spindle surface temperature greater than ambient temperature of 30 degrees, can be identified as the main heat seriously, immediately shut down cooling, a check








    Maintenance Caution


    (1) Spindle found abnormal sound, should immediately stop checking. If you can not be resolved, should be sent to the manufacturer or repair to professionals.


    (2) the operation of an abnormal burning smell, immediately stop checking. If you can not be resolved, should be sent to the manufacturer or repair to professionals.


    (3) If the spindle does not run the boot, do not start over, you should carefully check the following related matters: first check the drive parameters to determine the input and output voltage, the spindle parameter settings are correct. Second, check the power cord and wiring connector is plugged in and determine whether the contact connector problem.


    (4) Since the electric spindle is a high speed, high rigidity precision components and must therefore be sent back to me by professionals or for repair.
